• Fast aperture ensures a sharp image of the target.
• Target collimator for rough alignment.
• Penta prism makes it easy to read the circular vial.
• Erect image.
• Endless gon/angle setting using knobs with friction-braked rotation.
• Magnification: 24X
| Net weight | 1.48kg |
| Tool size | 23x13x14cm |
| Tripod mount thread | 5/8" |
| Degree of protection | IP54(dust and splash water protected) |
| Graduation interval | 1°or 1 gon |
| Graduation | 360° |
| Bubble sensitivity | 8'/2mm |
| Working range | ±15' |
| Stadia addition | |
| Stadia ratio | 100 |
| Field of view | 1°30' |
| Short focusing distance | 0.3m |
| Image | erect |
| Compensator setting accuracy | ±0.8" "Standard deviation for 1km double run leveling:" 2.0mm |
| Clear objective aperture | 36mm |
