• Manual/Auto Power Off
• Be accurate in testing AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Circuit continuity and frequency/duty
support diode and on/off test
• Convenient features like NCV and Live test
• Conductivity detection with buzzer
• Pocket size and support data hold
• Easy use in dark environment with backlight and flashlight function.
| Package | Color Box |
| Battery | 2 × AAA, 1.5V |
| KT-temperature range | -20℃ to 1000℃(-4℉ to 1832℉) |
| Resistance(Accuracy) | 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ/±(1.0%+3) |
| AC Current(Accuracy) | 600μA/6000μA/60mA/600mA/6A/10A/(±(1.5%+3)) |
| DC Current(Accuracy) | 600μA/6000μ600μA/6000μA/60mA/600mA/6A/10A/(±(1.2%+3)) |
| AC Voltage range(Accuracy) | 600mV/6V/60V/600V/(±(1.0%+3)) |
| DC Voltage range(Accuracy) | 600mV/6V/60V/600V/(±(0.5%+3)) |
| Max voltage | 600V AC/DC |
